Electric Therapy & Nursing Professional Bed — Product Performance Introduction
1. Product Overview
This product is a new-generation multi-functional electric therapy and nursing professional bed, integrating advanced electric control technology with humanized nursing care design. It is suitable for hospital wards, intensive care units (ICU), rehabilitation centers, nursing homes, and long-term home care settings. The bed features multi-position electric adjustment, effectively reducing the physical workload of medical staff while enhancing patient comfort and quality of care. It is the ideal equipment for modern medical and nursing facilities.
2. Core Technical Performance
2.1 Intelligent Electric Adjustment System
- Backrest Elevation: Infinitely adjustable from 0° to 75°, meeting patients' needs for sitting up, eating, reading, and cardiopulmonary assistance, effectively preventing hypostatic pneumonia.
- Leg Section Elevation: Independently adjustable from 0° to 45°, promoting venous return in the lower limbs and preventing deep vein thrombosis.
- Whole-Bed Height Adjustment: The bed surface height can be electrically adjusted for easier patient transfer and caregiver operation, while also matching bedside equipment (e.g., wheelchairs, stretchers) for safe transfer.
- Trendelenburg / Reverse Trendelenburg: The bed frame can tilt ±12° (head-down/head-up position) to meet special treatment needs such as shock resuscitation and post-operative drainage.
2.2 Precision Control & Safety Protection
- Handheld Remote Control: Equipped with a clear LCD/button panel for simple and intuitive operation, featuring backlight function for nighttime use.
- Dual Braking System: Central locking casters lock all four wheels simultaneously, ensuring the bed remains stable and secure.
- Anti-Pinch & Limit Protection: Motors run smoothly with precise limits and automatic cushioning during elevation to prevent accidental pinching.
- Emergency Backup Function: Equipped with a backup power supply / manual crank system, allowing basic position adjustment even during power outages to ensure uninterrupted care.
2.3 Material & Structural Performance
- Bed Frame: Made of high-quality cold-rolled steel plate, treated with pickling, phosphating, and electrostatic powder coating — sturdy, corrosion-resistant, and easy to clean.
- Bed Panels: Die-formed in one piece with a smooth, burr-free surface and ventilation holes to enhance breathability and prevent pressure ulcers.
- Side Rails: Four-section or two-section ABS/aluminum alloy folding rails with independent lifting and anti-pinch design, balancing safety and convenience.
- Silent Casters: Medical-grade anti-tangle silent swivel casters (≥125mm diameter) for smooth movement, flexible steering, and low noise.
3. Humanized Nursing Configurations
| Configuration | Description |
|---|---|
| Head/Foot Boards | High-strength ABS material, detachable for emergency access and cleaning |
| IV Pole Sockets | Reserved at four corners for quick installation of IV poles/equipment brackets |
| Drainage Hooks | Bedside hooks for hanging drainage bags |
| Mattress | Optional anti-decubitus pressure-relief mattress (alternating wave inflation) with breathable decompression |
| Overbed Table | Reversible, retractable table for meals and reading |
| Nurse Call Button | Bedside call system for one-touch patient-to-staff communication |
| Backup Power | Built-in UPS emergency power supply for several hours of continued operation during outages |
4. Technical Specifications
- Overall Dimensions (L×W): 2100mm × 960mm (wider/longer models available on request)
- Height Adjustment Range: 450mm – 750mm
- Backrest Angle: 0° – 75°
- Leg Section Angle: 0° – 45°
- Tilt Angle: ±12°
- Safe Working Load: ≥200kg (dynamic) / ≥250kg (static)
- Number of Motors: 4 (backrest, leg, height, and tilt independently controlled)
- Operating Voltage: AC 220V / 50Hz; Control Voltage: DC 24V (safety low voltage)
- Protection Rating: Motors IPX4 waterproof, suitable for routine cleaning and disinfection
5. Quality & Certifications
- Certified under ISO 13485 Medical Device Quality Management System and CE certification
- Warranty: 3 years for motors, 5 years for structural components
- Compliant with national medical electrical equipment safety standards with excellent electromagnetic compatibility, safe for use in ICU, operating rooms, and other critical environments
6. Applications
Suitable for internal medicine, surgery, orthopedics, gynecology, geriatrics, rehabilitation, ICU, and long-term home care — meeting a full range of needs from basic nursing care to special therapeutic positioning.
Summary: This electric therapy and nursing professional bed integrates electric position adjustment, intelligent control, safety protection, and humanized configurations. With stable performance, convenient operation, and reliable safety, it significantly improves clinical nursing efficiency and patient comfort — a trustworthy professional care device for hospitals and elderly care institutions at all levels.
电动治疗护理专业病床产品性能简介
一、产品概述
本产品为新一代多功能电动治疗护理专业病床，采用先进的电动控制技术与人性化护理设计理念，适用于医院病房、重症监护室（ICU）、康复中心、养老机构及家庭长期护理等场景。整床可实现多体位电动调节，有效减轻医护人员劳动强度，提升患者舒适度与护理质量，是现代化医疗护理的理想装备。
二、核心技术性能
1. 智能电动调节系统
- 背部升降：0°～75°无级调节，满足患者坐起、进食、阅读及心肺功能辅助需求，有效预防坠积性肺炎。
- 腿部升降：0°～45°独立调节，促进下肢血液回流，预防深静脉血栓形成。
- 整床升降：床面高度可电动调节，便于患者上下床及护工操作，同时可匹配不同床旁设备（如轮椅、担架）进行安全转移。
- 前后倾斜功能（Trendelenburg / Reverse Trendelenburg）：床体可实现±12°头低脚高/头高脚低体位，满足休克急救、术后引流等特殊治疗需求。
2. 精准控制与安全防护
- 手持式遥控器：配备清晰液晶/按键面板，操作简单直观，具有背光功能，便于夜间使用。
- 双保险制动系统：病床配备中控脚轮刹车，四轮同时锁定，确保床体稳固不滑动，保障患者安全。
- 防夹手与到位保护：电机运行平稳，限位精准，升降过程自动缓冲，防止意外夹伤。
- 断电应急功能：配备备用电源/手动摇杆应急装置，停电状态下仍可完成基本体位调节，保障特殊时期护理不间断。
3. 材质与结构性能
- 床架结构：采用优质冷轧钢板经酸洗磷化、静电喷塑处理，坚固耐用、耐腐蚀、易清洁。
- 床面板：采用模具冲压一次成型，表面平滑无毛刺，透气孔设计增强透气性，有效预防压疮。
- 护栏系统：配置四片式或两片式ABS/铝合金折叠护栏，可独立升降、防夹手设计，兼顾安全性与便捷性。
- 静音脚轮：采用医用级防缠绕静音万向轮，直径125mm以上，推行平稳、转向灵活、噪音低。
三、人性化护理配置
| 配置项 | 性能说明 |
|---|---|
| 床头尾板 | 高强度ABS材质，可拆卸设计，便于急救与清洁 |
| 输液架插孔 | 四角预留，可快速安装输液架/监护设备支架 |
| 引流挂钩 | 床侧配置，方便悬挂引流袋 |
| 床垫 | 可选配防褥疮减压床垫（波浪式交替充气），透气减压 |
| 餐桌板 | 可翻转伸缩式餐桌，方便患者用餐、阅读 |
| 呼叫按钮 | 床头配置呼叫器，患者随时一键呼叫医护人员 |
| 后备电源 | 内置UPS应急电源，断电可持续工作数小时 |
四、技术参数
- 床体尺寸（长×宽）：2100mm × 960mm（可选配加宽/加长型号）
- 床面高度调节范围：450mm～750mm
- 背部升降角度：0°～75°
- 腿部升降角度：0°～45°
- 前后倾斜角度：±12°
- 安全工作载荷：≥200kg（动态）/ ≥250kg（静态）
- 电机数量：4个（背部、腿部、升降、倾斜独立控制）
- 工作电压：AC 220V / 50Hz；控制电压：DC 24V安全电压
- 防护等级：电机IPX4防水，可日常清洁消毒
五、质量与认证
- 产品通过ISO 13485医疗器械质量管理体系认证及CE认证
- 整床质保：电机3年、结构部件5年
- 产品符合国家医用电气设备安全标准，电磁兼容性优良，可在ICU、手术室等环境中安全使用
六、适用范围
适用于内科、外科、骨科、妇产科、老年科、康复科、ICU重症监护及家庭长期照护等各类护理场景，能够满足从基础护理到特殊治疗体位的全方位需求。
总结：本电动治疗护理专业病床集电动体位调节、智能控制、安全防护与人性化配置于一体，性能稳定、操作便捷、安全可靠，能显著提升临床护理效率与患者舒适体验，是各级医疗机构及养老护理机构值得信赖的专业护理设备。
如果您需要，我可以进一步帮您：①精简为宣传海报版本、②翻译为英文版本、③生成产品规格参数表（Excel导出），请告诉我具体需求。
Me
2
AI Assistant
11.48s|7,300
好的，以下是英文翻译版本：
Electric Therapy & Nursing Professional Bed — Product Performance Introduction
1. Product Overview
This product is a new-generation multi-functional electric therapy and nursing professional bed, integrating advanced electric control technology with humanized nursing care design. It is suitable for hospital wards, intensive care units (ICU), rehabilitation centers, nursing homes, and long-term home care settings. The bed features multi-position electric adjustment, effectively reducing the physical workload of medical staff while enhancing patient comfort and quality of care. It is the ideal equipment for modern medical and nursing facilities.
2. Core Technical Performance
2.1 Intelligent Electric Adjustment System
- Backrest Elevation: Infinitely adjustable from 0° to 75°, meeting patients' needs for sitting up, eating, reading, and cardiopulmonary assistance, effectively preventing hypostatic pneumonia.
- Leg Section Elevation: Independently adjustable from 0° to 45°, promoting venous return in the lower limbs and preventing deep vein thrombosis.
- Whole-Bed Height Adjustment: The bed surface height can be electrically adjusted for easier patient transfer and caregiver operation, while also matching bedside equipment (e.g., wheelchairs, stretchers) for safe transfer.
- Trendelenburg / Reverse Trendelenburg: The bed frame can tilt ±12° (head-down/head-up position) to meet special treatment needs such as shock resuscitation and post-operative drainage.
2.2 Precision Control & Safety Protection
- Handheld Remote Control: Equipped with a clear LCD/button panel for simple and intuitive operation, featuring backlight function for nighttime use.
- Dual Braking System: Central locking casters lock all four wheels simultaneously, ensuring the bed remains stable and secure.
- Anti-Pinch & Limit Protection: Motors run smoothly with precise limits and automatic cushioning during elevation to prevent accidental pinching.
- Emergency Backup Function: Equipped with a backup power supply / manual crank system, allowing basic position adjustment even during power outages to ensure uninterrupted care.
2.3 Material & Structural Performance
- Bed Frame: Made of high-quality cold-rolled steel plate, treated with pickling, phosphating, and electrostatic powder coating — sturdy, corrosion-resistant, and easy to clean.
- Bed Panels: Die-formed in one piece with a smooth, burr-free surface and ventilation holes to enhance breathability and prevent pressure ulcers.
- Side Rails: Four-section or two-section ABS/aluminum alloy folding rails with independent lifting and anti-pinch design, balancing safety and convenience.
- Silent Casters: Medical-grade anti-tangle silent swivel casters (≥125mm diameter) for smooth movement, flexible steering, and low noise.
3. Humanized Nursing Configurations
| Configuration | Description |
|---|---|
| Head/Foot Boards | High-strength ABS material, detachable for emergency access and cleaning |
| IV Pole Sockets | Reserved at four corners for quick installation of IV poles/equipment brackets |
| Drainage Hooks | Bedside hooks for hanging drainage bags |
| Mattress | Optional anti-decubitus pressure-relief mattress (alternating wave inflation) with breathable decompression |
| Overbed Table | Reversible, retractable table for meals and reading |
| Nurse Call Button | Bedside call system for one-touch patient-to-staff communication |
| Backup Power | Built-in UPS emergency power supply for several hours of continued operation during outages |
4. Technical Specifications
- Overall Dimensions (L×W): 2100mm × 960mm (wider/longer models available on request)
- Height Adjustment Range: 450mm – 750mm
- Backrest Angle: 0° – 75°
- Leg Section Angle: 0° – 45°
- Tilt Angle: ±12°
- Safe Working Load: ≥200kg (dynamic) / ≥250kg (static)
- Number of Motors: 4 (backrest, leg, height, and tilt independently controlled)
- Operating Voltage: AC 220V / 50Hz; Control Voltage: DC 24V (safety low voltage)
- Protection Rating: Motors IPX4 waterproof, suitable for routine cleaning and disinfection
5. Quality & Certifications
- Certified under ISO 13485 Medical Device Quality Management System and CE certification
- Warranty: 3 years for motors, 5 years for structural components
- Compliant with national medical electrical equipment safety standards with excellent electromagnetic compatibility, safe for use in ICU, operating rooms, and other critical environments
6. Applications
Suitable for internal medicine, surgery, orthopedics, gynecology, geriatrics, rehabilitation, ICU, and long-term home care — meeting a full range of needs from basic nursing care to special therapeutic positioning.
Summary: This electric therapy and nursing professional bed integrates electric position adjustment, intelligent control, safety protection, and humanized configurations. With stable performance, convenient operation, and reliable safety, it significantly improves clinical nursing efficiency and patient comfort — a trustworthy professional care device for hospitals and elderly care institutions at all levels.
